4-Port 140W GaN Charger (GNC-140)

4-Port 140W GaN Charger (GNC-140) - Image 3

4-Port 140W GaN Charger (GNC-140) - Image 4

4-Port 140W GaN Charger (GNC-140)

Product Details

Supports charging of up to 4 devices simultaneously with a maximum total output of 140W
Equipped with 2 x USB-C® PD 3.1 up to 140W, 1 x USB-C PD 3.0 up to 20W, and 1 x USB-A QC 3.0 up to 18W
Integrated GaN technology provides efficient charging and generates less heat
Great travel companion thanks to foldable US prongs, replaceable EU and UK plugs and slim, compact design
Supports super-fast charging with USB Power Delivery 3.1 & 3.0, PPS, and Quick Charge 3.0
Programmable Power Supply (PPS) technology delivers the right amount of power needed for the ideal charge
Made with high-quality, flame-resistant materials and featuring four safety protection systems, including over-current protection,
over-voltage protection, short circuit protection, and over-temperature protection
Plastic-free packaging

#32203

140W 4-in-1 Charging

Verbatim’s 140W GaN Charger combines two USB-C PD 3.1 (PPS) 140W ports, one USB-C PD 20W port and one USB-A QC 3.0 port in a sleek, palm sized design. USB-C1 & C2 both maintain up to 65W, for rapid charging of two laptops while these two ports being used together.

Ideal for the office, home or travelling to power your laptop, tablet, smartphone, gaming devices, and more.

GaN Technology

Galliam Nitride (GaN) technology delivers high-powered, fast, efficient charging, and generates less heat. GaN chargers are smaller and lighter than traditional silicon-based chargers. With its foldable US prongs and replaceable EU and UK plugs, it’s the ultimate travel companion.

Safe and Reliable

The GaN charger is made with high-quality, flame-resistant materials and features four safety protection systems, including over-current protection, over-voltage protection, short circuit protection, and over-temperature protection to ensure your safety while charging. It is certified with IEC62368, CE, UKCA, RoHS, Safety Mark, and covered by Global Product Liability Insurance.

Product Details
Specifications
Pack Contents

Supports charging of up to 4 devices simultaneously with a maximum total output of 140W
Equipped with 2 x USB-C® PD 3.1 up to 140W, 1 x USB-C PD 3.0 up to 20W, and 1 x USB-A QC 3.0 up to 18W
Integrated GaN technology provides efficient charging and generates less heat
Great travel companion thanks to foldable US prongs, replaceable EU and UK plugs and slim, compact design
Supports super-fast charging with USB Power Delivery 3.1 & 3.0, PPS, and Quick Charge 3.0
Programmable Power Supply (PPS) technology delivers the right amount of power needed for the ideal charge
Made with high-quality, flame-resistant materials and featuring four safety protection systems, including over-current protection,
over-voltage protection, short circuit protection, and over-temperature protection
Plastic-free packaging

Input Voltage: AC 100-240~ 50/60Hz 1.8A max.
Single port output:

USB-C1 PD 3.1 Output: 3.3-21V ⎓ 5A, 5V ⎓ 3A, 9V ⎓ 3A, 12V ⎓ 3A, 15V ⎓ 3A, 20V ⎓ 5A, 28V ⎓ 5A (140W max.)
USB-C2 PD 3.1 Output: 3.3-21V ⎓ 5A, 5V ⎓ 3A, 9V ⎓ 3A, 12V ⎓ 3A, 15V ⎓ 3A, 20V ⎓ 5A, 28V ⎓ 5A (140W max.)
USB-C3 PD 3.0 Output: 5V ⎓ 3A, 9V ⎓ 2.22A, 12V ⎓ 1.67A (20W max.)
USB A QC 3.0 Output: 5V ⎓ 3A, 9V ⎓ 2A, 12V ⎓ 1.5A (18W max.)

Combined port output:

USB-C1+USB-C2 Output: 65W + 65W
USB-C1+USB-C3 Output: 100W + 20W
USB-C1+USB-A Output: 100W + 18W
USB-C2+USB-C3 Output: 100W + 20W
USB-C2+USB-A Output: 100W + 18W
USB-C3+USB-A Output: 5V ⎓ 3A
USB-C1+USB-C2+USB-C3 Output: 65W + 45W + 20W
USB-C1+USB-C2+USB-A Output: 65W + 45W + 18W
USB-C1+USB-C3+USB-A Output: 100W + 15W (USB-C3+USB-A)
USB-C2+USB-C3+USB-A Output: 100W + 20W (USB-C3+USB-A)
USB-C1+USB-C2+USB-C3+USB-A Output: 65W + 45W + 15W (USB-C3+USB-A)
Total Output: 140W max

Safety protection systems:
Short circuit protection
Over-voltage protection
Over-current protection
Over-temperature protection
Material: Plastic Housing: PC Fireproof material
Dimensions (W x H x D): 76.5 x 67.7 x 31.3 mm
Weight: 270 grams
