2 Port 33W PD & QC 3.0 GaN Charger

SKU: 66791
  • Newest ‘GaN II’ technology, smaller size with higher power
  • Equipped with 1 Type C PD 3.0 port and 1 USB-A QC 3.0 port
  • Type C PD 3.0 port supports up to 30W charging when being used alone
  • Type C port also supports PPS, providing up to 33W charging when being used alone
  • USB-A QC 3.0 port supports up to 18W charging when being used alone
  • With a maximum total output of 33W
  • Over current protection, over voltage protection, short circuit protection, over temperature protection, smart IC

Newest ‘GaN II’ technology

By utilizing the GaN II technology, the charger achieves high power output with a compact size that makes it ideal for use at home, in the office and overseas.

Supports PD 3.0, PPS & QC 3.0

Equipped with 1 Type C PD 3.0 and 1 USB-A QC 3.0 ports. Type C PD 3.0 port supports up to 30W charging when being used alone. It also supports PPS up to 33W. USB-A QC 3.0 port supports up to 18W when being used alone. With a total maximum output of 33W.

Charge up to 2 devices simultaneously

Dual ports allow charging up to 2 devices simultaneously. When 2 ports are being used at the same time, the total maximum output is 15W (5Vdc/3A sharing).

4 protection systems

It is designed with 4 protection systems: over current protection, over voltage protection, short circuit protection and over temperature protection. Therefore, the quality and stability are ensured.

Multi-national Safety Certificates

The USB Charger has gained IEC62368 (H.K.), FCC (U.S.), CE (EU) and RoHS certificates. It is also supported with Global Product Liability Insurance.

Specifications:

  • Input: 100Vac – 240Vac, 50/60Hz, 0.8A (Max.)
  • Output:

Type C (PD 3.0) – 5Vdc/3A, 9Vdc/3A, 12Vdc/2.5A, 15Vdc/2A, 20Vdc/1.5A (Max. 30W).
(PPS Supported) – 3.3-11Vdc/3A, 3.3-16Vdc/2A (Max. 33W).
USB-A (QC 3.0) – 3.6-6.5Vdc/3A, 6.5-9Vdc/2A, 9-12Vdc/1.5A (Max. 18W).
Type C + USB-A – 5Vdc/3A sharing (Max. 15W).

  • Over current protection, Over voltage protection, Short circuit protection, Over temperature protection, Smart IC
  • Product dimensions: 71.8 x 48.7 x 43 (mm)
  • Product weight: 68g
  • Material: PC Flame resistant material
  • Warranty : 1-year limited warranty
